| Brand Name: | XSW PCB |
| Model Number: | XSWPCB |
| MOQ: | 1 |
| Price: | Negotiable |
| Payment Terms: | Western Union |
| Supply Ability: | 1 Million Square feet/per month |
| Layer Count | 4-Layer |
| Material | Rogers |
| Board Thickness | 1.6mm |
| Copper Thickness | 1.5/1/1/1.5 oz |
| Minimum Hole Size | 0.25 mm |
| Minimum Line Width | 0.12mm |
| Minimum Line Spacing | 0.12 mm |
| Solder Mask Color | Green |
| Surface Finish | ENIG |
| Application Field | Industrial control system |
Product Description:
Industrial control circuit board is a type of printed circuit board specifically designed for industrial control systems. It is also known as factory automation board or industrial control system board.
Product Overview
The industrial control circuit board is a multilayer printed circuit board made of FR-4 material. It has a minimum aperture of 0.2 mm and a copper thickness of 1 oz. The surface finish of this PCB is immersion gold (ENIG), providing a smooth and flat surface for component placement and soldering. The combination of these features makes the industrial control circuit board efficient and reliable in industrial control systems.
Features and Advantages
The industrial control circuit board offers numerous features and advantages that make it an ideal choice for industrial control systems. Some of the key features and advantages include:
Durability: Made of high-quality FR-4 material, the industrial control PCB is highly durable and capable of withstanding harsh industrial environments.
High Precision: With a minimum aperture of 0.2 mm, this PCB achieves high precision in component placement, ensuring smooth operation of industrial control systems.
Multilayer Design: The industrial control circuit board is a multilayer board, allowing for higher component density and better signal transmission, making it suitable for complex industrial control systems.
Efficient Heat Dissipation: The 1 oz copper thickness of this PCB enables efficient heat dissipation, preventing components from overheating and ensuring stable operation of industrial control systems.
Cost-Effectiveness: Despite its advanced features and advantages, the industrial control circuit board remains an affordable solution for industrial control systems, making it a popular choice among manufacturers.
| Item | Mass Production Capability | Extreme Capability |
|---|---|---|
| Board Thickness Range | 0.3~6.0mm | 0.3~6.0mm |
| Exposure Alignment Accuracy | ±0.015mm | ±0.005mm |
| Minimum Annular Ring | Single side ≥0.05mm | Single side ≥0.05mm |
| Min Line Width/Space (1/3oz base copper) | 0.05mm / 0.05mm | 0.045mm / 0.045mm |
| Min Line Width/Space (1/2oz base copper) | 0.05mm / 0.05mm | 0.05mm / 0.05mm |
| Min Line Width/Space (1oz base copper) | 0.075mm / 0.075mm | 0.075mm / 0.075mm |
| Etching Tolerance (1/3oz base copper) | ±0.005mm | ±0.005mm |
| Etching Tolerance (1/2oz base copper) | ±0.005mm | ±0.005mm |
| Etching Tolerance (1oz base copper) | ±0.0075mm | ±0.0075mm |
| Gold Finger Total Pitch Tolerance | <30mm: ±0.05mm 30~60mm: ±0.075mm |
<30mm: ±0.03mm 30~60mm: ±0.05mm |
