| Brand Name: | XSW PCB |
| Model Number: | XSWPCB |
| MOQ: | 1 |
| Price: | Negotiable |
| Payment Terms: | Western Union |
| Supply Ability: | 1 Million Square feet/per month |
| Layer Count | 8 Layers |
| Material | FR4 TG150 |
| Board Thickness | 1.0 mm |
| Copper Thickness | 1/1/1/1/1/1/1/1 oz |
| Minimum Hole Size | 0.2mm |
| Minimum Line Width | 0.1mm |
| Minimum Line Spacing | 0.1mm |
| Solder Mask Color | Green |
| Surface Finish | Lead-Free HASL (Tin Spray) |
| Application Field |
Industrial Control and Automation Systems |
We provide one-stop OEM manufacturing service for multilayer printed circuit boards and complete PCBA assembly solutions. Our factory produces reliable multilayer PCBs ranging from 4 layers up to high-layer count boards, supporting customized size, thickness, impedance control and various surface finishes. Equipped with advanced SMT, DIP assembly lines, we can complete component procurement, surface mount, through-hole soldering, testing and final packaging according to customers’ Gerber files, BOM and technical requirements.
Our multilayer PCBs are widely adopted in industrial control, communication equipment, medical electronics, automotive electronics, consumer electronics, IoT devices and server hardware. Strict quality management conforms to IPC, UL, RoHS standards to guarantee stable performance for commercial and industrial applications. We support prototype small-batch trial orders as well as mass-volume production.
1.Custom OEM multilayer PCB fabrication: 4L~20+ layers available
2.One-stop service: PCB production + Components sourcing + SMT & DIP PCBA assembly3.Support 3.impedance control, buried/blind vias, HDI high density circuit design
4.Multiple surface finishes: ENIG, OSP, Immersion Silver, Immersion Tin, Hard Gold Plating
5.Compliant with UL, RoHS, IPC-A-610 international quality standards
6.Advanced testing: AOI, X-Ray, ICT, Flying Probe electrical testing
7.Accept prototype sample orders, small batch and large scale mass production
8.Professional engineering support for Gerber file review, DFM optimization
9.Wide material options: FR-4, high TG FR4, aluminum base, polyimide material
10.Strict quality inspection to reduce defect rate and ensure long-term working stability.
| Item | Mass Production Capability | Extreme Capability |
|---|---|---|
| Board Thickness Range | 0.3~6.0mm | 0.3~6.0mm |
| Exposure Alignment Accuracy | ±0.015mm | ±0.005mm |
| Minimum Annular Ring | Single side ≥0.05mm | Single side ≥0.05mm |
| Min Line Width/Space (1/3oz base copper) | 0.05mm / 0.05mm | 0.045mm / 0.045mm |
| Min Line Width/Space (1/2oz base copper) | 0.05mm / 0.05mm | 0.05mm / 0.05mm |
| Min Line Width/Space (1oz base copper) | 0.075mm / 0.075mm | 0.075mm / 0.075mm |
| Etching Tolerance (1/3oz base copper) | ±0.005mm | ±0.005mm |
| Etching Tolerance (1/2oz base copper) | ±0.005mm | ±0.005mm |
| Etching Tolerance (1oz base copper) | ±0.0075mm | ±0.0075mm |
| Gold Finger Total Pitch Tolerance | <30mm: ±0.05mm 30~60mm: ±0.075mm |
<30mm: ±0.03mm 30~60mm: ±0.05mm |
