FR4 TG150 6 Layer ENIG PCB Board 0.1mm Line Width For Mobile Phone Modules

FR4 TG150 6 Layer ENIG PCB Board 0.1mm Line Width For Mobile Phone Modules

Brand Name: XSW PCB
Model Number: XSWPCB
MOQ: 1
Price: Negotiable
Payment Terms: Western Union
Supply Ability: 1 Million Square feet/per month
Detail Information
Place of Origin:
China
Certification:
UL ,IOS9000
Layer Count:
6 Layers
Material:
FR4 TG150
Board Thickness:
1.6mm
Copper Thickness:
1/1/1/1 Oz
Minimum Hole Size:
0.2mm
Minimum Line Width:
0.1mm
Supply Ability:
1 Million Square feet/per month
Highlight:

6 Layer ENIG PCB

,

FR4 TG150 ENIG PCB

,

6 Layer Mobile Phone PCB Board

Product Description
6-layer ENIG Blue Mobile Phone Module
This advanced 6-layer mobile phone module features ENIG surface finish and blue solder mask, specifically designed for mobile communication applications with high-frequency performance requirements.
Key Specifications
Specification Value
Layer Count 6 Layers
Material FR4
Board Thickness 1.2mm
Copper Thickness 1/1/1/1 oz
Minimum Hole Size 0.2mm
Minimum Line Width 0.1mm
Minimum Line Spacing 0.1mm
Solder Mask Color Blue
Surface Finish ENIG
Application Field Mobile Communication
Critical Production Processes
  • Inner layer core board undergoes browning treatment for uniform film density
  • CCD automatic alignment exposure with ±25μm interlayer accuracy
  • 100% AOI inspection and line width measurement after inner layer etching
  • Hot oil press lamination with ±2°C temperature uniformity and vacuum assist
  • X-Ray measurement with ≤75μm interlayer misalignment control
  • Scanning acoustic microscopy for delamination and void detection
  • High-precision CNC drilling with backup board structures
  • Desmearing and potassium permanganate treatment before electroless copper
  • Vacuum screen printer for solder mask application
  • Plasma roughening before ENIG for enhanced adhesion
  • Comprehensive testing including tape pull, bend testing, and TDR impedance
Technical Specifications
Item Mass Production Capability Extreme Capability
Board Thickness Range 0.3~6.0mm 0.3~6.0mm
Exposure Alignment Accuracy ±0.015mm ±0.005mm
Minimum Annular Ring Single side ≥0.05mm Single side ≥0.05mm
Min Line Width/Space (1/3oz base copper) 0.05mm / 0.05mm 0.045mm / 0.045mm
Min Line Width/Space (1/2oz base copper) 0.05mm / 0.05mm 0.05mm / 0.05mm
Min Line Width/Space (1oz base copper) 0.075mm / 0.075mm 0.075mm / 0.075mm
Etching Tolerance (1/3oz base copper) ±0.005mm ±0.005mm
Etching Tolerance (1/2oz base copper) ±0.005mm ±0.005mm
Etching Tolerance (1oz base copper) ±0.0075mm ±0.0075mm
Gold Finger Total Pitch Tolerance <30mm: ±0.05mm
30~60mm: ±0.075mm
<30mm: ±0.03mm
30~60mm: ±0.05mm
