Precision Communication PCB For Wireless Module Integration & Iot Connectivity Solutions

Precision Communication PCB For Wireless Module Integration & Iot Connectivity Solutions

Brand Name: XSW PCB
Model Number: XSWPCB
MOQ: 1
Price: Negotiable
Payment Terms: Western Union
Supply Ability: 1 Million Square feet/per month
Detail Information
Place of Origin:
China
Certification:
UL ,IOS9000
Layer Count:
4L
Material:
FR4-TG140
Board Thickness:
1.6 Mm
Copper Thickness:
1/1/1/1 Oz
Minimum Hole Size:
0.2 Mm
Minimum Line Width:
0.12 Mm
Minimum Line Spacing:
0.1 Mm
Supply Ability:
1 Million Square feet/per month
Highlight:

Precision Communication PCB

,

FR4 TG140 Communication PCB

Product Description
Precision Communication PCB

Tailored for integration into wireless communication modules and IoT connectivity solutions

Product Specifications
Layer Count 4L
Material FR4-TG140
Board Thickness 1.6 MM
Copper Thickness 1/1/1/1 oz
Minimum Hole Size 0.2 mm
Minimum Line Width 0.12 mm
Minimum Line Spacing 0.1 mm
Solder Mask Color Blue
Surface Finish ENIG (Electroless Nickel Immersion Gold)
Application Field Communication Products
Key Features: 4-layer PCB, 0.2mm BGA pitch, with gold fingers

Xunsiwei PCB — Born for High-Speed Communication, Practitioner of 0.2mm BGA Precision Interconnection

We understand that the core of communication boards lies not in simple "layer count stacking," but in ensuring signal integrity under extreme precision scenarios. Xunsiwei focuses on BGA packaging and HDI technologies, providing deep solutions from design optimization to volume delivery for high-performance communications, IoT gateways, and intelligent electronic systems.

In-Depth Customization Capabilities

Our understanding of "customization" goes beyond simple dimensional modifications—it's about collaborative optimization starting from the design phase:

  • DFM Pre-Assessment: Intervention during your layout and routing phase to anticipate potential risks in BGA fan-out, impedance stack-up, and gold finger tracing
  • Special Process Combination Capability: Simultaneous realization of 0.2mm BGA + gold fingers + selective ENIG + impedance control on 4-layer boards, formed in one process—no secondary processing required
Reliability Assurance System
Test Item Industry Standard (Spot Check) Xunsiwei Standard
Electrical Test Flying probe spot check 100% full inspection (flying probe + fixture), zero tolerance for open/short circuits
AOI Inspection Outer layer only Full-process AOI for inner and outer layers, no hiding place for fine line defects
Thermal Stress Test 288℃/10S 288℃/20S, 3 cycles, simulating extreme operating conditions
Impedance Consistency First article confirmation Batch sampling + SPC process control, CpK ≥ 1.33
